CCGT060202K-1DNF
Positive PCD turning insert, 80° rhombic, with hole. Inscribed circle diameter 6.35 mm; Thickness 2.38 mm; Nose radius 0.2 mm.
Price and availability to be confirmed in the quotation.
Original manufacturer documentDocument in its original language; images and PDF have not been translated.PDF page 147 · View full tableDrawing and dimensions
Data for CCGT060202K-1DNF
Row data
- Teeth
- PCD Grade · DNN125P
Dimensions
- LE (mm)
- IC (mm)
- S (mm)
- D1 (mm)
- RE (mm)
Values and tolerances follow the original headers. Interpret catalogue symbols using the PDF legend; they do not indicate current stock.
View page 147 of the original PDF ↗
